D04E05HWST00 DC Axial Compact Fan 40x40x10mm 11m³/h 2.2W 24V Sleeve Bearing
SKU
D04E05HWST00
Buy 50 for
£6.38
each and save 5%
£6.72
| SKU | D04E05HWST00 |
|---|---|
| Lead Times | variable - contact us on 01782 349 430 |
| Manufacturer | FANDISEU |
| Current Type | DC |
| Fan Type | DC Compact Axial Fan |
| ATEX | No |
| Rated Voltage | 24V.d.c. |
| Frequency | 50Hz |
| Dimensions | 40x40x10mm |
| Connection Type | Cable |
| Cable Length | 11.8" - 300mm |
| Max Air Flow (50Hz) | 11(m³/h) |
| Airflow Range (50Hz) | < 100m³/h |
| Bearing Type | Ball Bearing |
| Speed (RPM) | 6000 |
| IP Rating | IP20 |
Description
Specially designed for control panels and enclosures, the AC Axial Compact Fan range from Axair online offers:
- Compact sizes
- Ball & Sleeve Bearing options on many lines
- Dust and water protection
- A wide selection of airflows
Standard Specifications of D04E05HWST00 EC Axial Compact Fan:
- Casing Material: Glass fibre reinforced plastic
- Impeller Material: Glass fibre reinforced plastic
- Motor protection: Impedance
- Rated temperature range: from -20°C to +70°C Lifetime L10 at 40°C: 70,000 h
- Electrical connection: 2 leads AWG26 UL1007 30mm long
- Weight: 0.17 kg
- Approvals: CE
| Dimension | 40x40x10 |
| Rated Voltage | 24v DC |
| Rated Power (W) | 2.2 |
| Max Air Flow (m3/h) | 11 |
| Static Pressure (Pa) | 25 |
| Rated Speed (RPM) | 4800 |
| Noise (dB(A) | 22.0 |
| Bearing Type | Sleeve |
