D06A05HWHA00 DC Axial Compact Fan 60x60x25 40m³/h 2.88W 24V Hypro Bearing

D06A05HWHA00 DC Axial Compact Fan 60x60x25 40m³/h 2.88W 24V Hypro Bearing

SKU
D06A05HWHA00
Buy 60 for £8.44 each and save 5%
In Stock
View Downloads
Manufacturer FANDISEU
Axial Fan Dimensions 60x60x25mm
Max Air Flow (50Hz) 40(m³/h)
Airflow Range (50Hz) < 100m³/h
Bearing Type Hypro Bearing
Voltage 24Vd.c.

Description

Specially designed for control panels and enclosures, the AC Axial Compact Fan range from Axair online offers:

  • Compact sizes
  • Ball & Sleeve Bearing options on many lines
  • Dust and water protection
  • A wide selection of airflows

Standard Specifications of D06A05HWHA00 EC Axial Compact Fan:

  • Casing Material: Glass fibre reinforced plastic
  • Impeller Material: Glass fibre reinforced plastic
  • Motor protection: Impedance
  • Rated temperature range: from -20°C to +70°C Lifetime L10 at 40°C: 70,000 h
  • Electrical connection: 2 leads  AWG26 UL1007 30mm long
  • Weight: 0.17 kg
  • Approvals: CE



Dimension 60x60x25
Rated Voltage 24Vd.c
Rated Power (W) 2.88
Max Air Flow (m3/h) 40
Static Pressure (Pa) 63
Rated Speed (RPM) 4500
Noise  (dB(A) 33.1
Bearing Type Hypro Bearing
