D08A04HWBAF0 DC Axial Compact Fan 80x80x25mm IP68 63m³/h 2.12W 12V.d.c Ball Bearing
SKU
D08A04HWBAF0
Buy 50 for
£26.77
each and save 5%
£28.18
| SKU | D08A04HWBAF0 |
|---|---|
| Lead Times | variable - contact us on 01782 349 430 |
| Manufacturer | FANDISEU |
| Current Type | DC |
| Fan Type | DC Compact Axial Fan |
| ATEX | No |
| Rated Voltage | 12V.d.c. |
| Frequency | 50Hz |
| Dimensions | 80x80x25mm |
| Connection Type | Cable |
| Cable Length | 11.8" - 300mm |
| Max Air Flow (50Hz) | 63(m³/h) |
| Airflow Range (50Hz) | < 100m³/h |
| Bearing Type | Ball Bearing |
| Speed (RPM) | 3000 |
| IP Rating | IP68 |
Description
Specially designed for control panels and enclosures, the DC Axial Compact Fan range from Axair online offers:
- Compact sizes
- Ball & Sleeve Bearing options on many lines
- Dust and water protection
- A wide selection of airflows
Standard Specifications of D08A04HWBAF0 DC Axial Compact Fan:
- Casing material: Black fibreglass reinforced plastic (PBT) UL 94V-0
- Impeller material:Black fibreglass reinforced plastic (PBT) UL 94V-0
- Protection degree: IP68, according to EN 60529 standard
- Fixing system: by No. 4 M4 screws
- Motor protection: Impendance
- Storage temperature: from -40°C to +70°C
- Rated temperature range: -20°C to +70°C
- Lifetime L10 at 40°C: 70,000
- Electrical connection: 2 leads 24AWG UL 1007, 300 mm long.
- Weight: 86g
- Approvals: UL E223195
| Dimension | 80x80x25 |
| Rated Voltage | 12V.d.c. |
| Rated Power (W) | 2.12 |
| Max Air Flow (m3/h) | 63 |
| Static Pressure (Pa) | 39 |
| Rated Speed (RPM) | 3000 |
| Noise (dB(A)) | 35.8 |
| Bearing Type | Ball |
