D09A04HWSZ00 DC Axial Compact Fan 92x92x25mm 95m³/h 3w 12V Sleeve Bearing

D09A04HWSZ00 DC Axial Compact Fan 92x92x25mm 95m³/h 3w 12V Sleeve Bearing

SKU
D09A04HWSZ00
Buy 45 for £4.44 each and save 5%
tick In Stock
Manufacturer FANDISEU
Axial Fan Dimensions 92x92x25mm
Max Air Flow (50Hz) 95(m³/h)
Airflow Range (50Hz) < 100m³/h
Bearing Type Sleeve Bearing
Voltage 12Vd.c.

Description

Specially designed for control panels and enclosures, the DC Axial Compact Fan range from Axair online offers:

  • Compact sizes
  • Ball & Sleeve Bearing options on many lines
  • Dust and water protection
  • A wide selection of airflows

Standard Specifications of D09A04HWSZ00 DC Axial Compact Fan:

  • Casing material: Black fibreglass reinforced plastic (PBT) UL 94V-0
  • Impeller material:Black fibreglass reinforced plastic (PBT) UL 94V-0
  • Protection degree: IP20, according to EN 60529 standard
  • Fixing system: by No. 4 M4 screws
  • Motor protection: by impedance
  • Storage temperature: from -40°C to +70°C
  • Rated temperature range: from -10°C to +70°C Lifetime L10 at 40°C: 70,000 h
  • Electrical connection: 3 leads 24AWG UL 1007, 300 mm long
  • Approvals: UL E223195
  • Weight: 92 g



Dimension 92x92x25
Rated Voltage 12 Vd.c.
Rated Power (W) 3
Max Air Flow (m3/h) 95
Static Pressure (Pa) 37
Rated Speed (RPM) 2900
Noise  (dB(A)) 37.5
Bearing Type Sleeve


Download the datasheet for D09A04HWSZ00
