A17C12HWBF00 AC Axial Compact Fan 172x150x51mm 289m³/h 32W 115V Ball Bearing
SKU
A17C12HWBF00
Buy 20 for
£65.36
each and save 5%
£68.80
In Stock
| SKU | A17C12HWBF00 |
|---|---|
| Manufacturer | FANDISEU |
| Current Type | AC |
| Fan Type | AC Compact Axial Fan |
| ATEX | No |
| Rated Voltage | 115V.a.c. |
| Frequency | 50-60Hz |
| Dimensions | 172x150x51mm |
| Connection Type | Cable |
| Cable Length | 13.7" - 350mm |
| Max Air Flow (50Hz) | 289(m³/h) |
| Airflow Range (50Hz) | 250 to 500m³/h |
| Bearing Type | Ball Bearing |
| Speed (RPM) | 2750 |
| IP Rating | IP44 |
Description
Specially designed for control panels and enclosures, the AC axial compact fan range from Axair online offers:
- Compact sizes
- Ball & Sleeve Bearing options on many lines
- Dust and water protection
- A wide selection of airflows
Standard Specifications of A17C12HWBF00 AC Axial Compact Fan:
- Casing Material: Black warnished aluminum UL 94V-0
- Impeller Material: Black fibreglass reinforced plastic (PBT PC) UL 94V-0
- Protection degree: IP44, according to EN 60529 standard
- Fixing system: by No 4 M4 screws
- Motor protection: thermal
- Storage temperature: from -40°C to +80°C
- Rated temperature range: from -40°C to +60°C Lifetime L10 at 40°C: 40,000 h
- Electrical connection: 2 leads 22AWG UL 1015, 300 mm long
- Weight: 0.90kg
- Approvals: UL E223195
| Dimension | 172x150x51 |
| Rated Voltage | 115V.a.c |
| Rated Power (50/60Hz) | 32/28 |
| Max Air Flow (m3/h) | 289/331 |
| Static Pressure (50/60Hz) | 105/95 |
| Rated Speed (50/60Hz) (RPM) | 2750/3100 |
| Noise (50/60Hz) (dB(A)) | 50.0/55.0 |
| Bearing Type | Ball |
