D08A05HWSA00 DC Axial Compact Fan 80x80x25mm 67m³/h 3.8W 24V Sleeve Bearing

D08A05HWSA00 DC Axial Compact Fan 80x80x25mm 67m³/h 3.8W 24V Sleeve Bearing

SKU
D08A05HWSA00
Buy 50 for £6.74 each and save 5%
tick In Stock
View Downloads chevron-right
Manufacturer FANDISEU
Axial Fan Dimensions 80x80x25mm
Max Air Flow (50Hz) 67(m³/h)
Airflow Range (50Hz) < 100m³/h
Bearing Type Sleeve Bearing
Voltage 24Vd.c.

Description

Specially designed for control panels and enclosures, the DC Axial Compact Fan range from Axair online offers:

  • Compact sizes
  • Ball & Sleeve Bearing options on many lines
  • Dust and water protection
  • A wide selection of airflows

Standard Specifications of D08A05HWSA00 DC Axial Compact Fan:

  • Casing material: Black fibreglass reiforced plastic (PBT) UL 94V-0
  • Impeller material: Black fibreglass reiforced plastic (PBT) UL 94V-0
  • Protection degree: Impendance
  • Storage temperature: from -10°C to +60°C
  • Rated temperature range: from -10°C to +60°C Lifetime L10 at 40°C: 70,000
  • Weight: 84 g



Dimension 80x80x25
Rated Voltage 24Vd.c
Rated Power (W) 3.8
Max Air Flow (m3/h) 67
Static Pressure (Pa) 41
Rated Speed (RPM) 3100
Noise  (dB(A)) 34.4
Bearing Type Sleeve
