Explosion Proof (ATEX) EC Compact Axial Fan IP68 120x120x38mm 5.8W HEC1238HA
SKU
HEC1238HA
Buy 40 for
£40.38
each and save 5%
£42.50
In Stock
| SKU | HEC1238HA |
|---|---|
| Manufacturer | AXAIRREF |
| Current Type | EC |
| Fan Type | ATEX Compact Axial Fan |
| ATEX | Yes |
| Rated Voltage | 115-230V.a.c |
| Frequency | 50-60Hz |
| Dimensions | 120x120x38mm |
| Connection Type | Cable |
| Cable Length | 11.8" - 300mm |
| Max Air Flow (50Hz) | 196(m³/h) |
| Airflow Range (50Hz) | 100 to 250m³/h |
| Bearing Type | Ball Bearing |
| Speed (RPM) | 3000 |
| IP Rating | IP68 |
Description
IMPORTANT NOTE: The HEC range is an ATEX "U" marked component & must be integrated into a piece of equipment that is then rated as a complete stand-alone item. This product is not suitable for use to ventilate an ATEX zoned area such as, UPS rooms, battery charging etc. For applications that require a stand-alone ATEX rated product, please view our industrial range of ATEX fans.
The HEC1238HA is the high speed variant of the ATEX EC IP69 compact axial fan. The range consists of 3 ATEX compact axial fans in the size 120x120x38 in 3 different speeds, high, medium and low. The HEC1238HA ATEX EC compact axial fan offers a maximum airflow of 196m3/h and low noise volumes of 45dB(A) at 3000rpm. The HEC range, exclusive to Axair Fans are ATEX, also known as explosion proof, certified making the product suitable in hazardous environments up to zone 2. Using an ATEX fan gives confidence to users by incorporating a fully encapsulated motor and spark proof components. The frame axial fan uses ball bearings, increasing the lifespan of the products making it more cost effective.
The HEC’s were created with a commercial refrigeration application in mind. As environmental laws crack down on pollutants affecting the ozone layer and global warming more and more companies are switching to Hydrocarbon refrigerants. The HEC’s can also be used in a wide range of applications such as control panels and enclosures.
Specially designed for control panels and enclosures, the EC Axial Compact Fan HEC range from Axair online offers:
- Compact size
- Dust and water tight, ingress protection to IP68
Standard Specifications of HEC1238HA EC Compact Axial Fan with IP68 Ingress Protection:
- Casing Material: Thermoplastic UL 94V-0/Black
- Impeller Material: Thermoplastic UL 94V-0/Black
- Protection degree: IP68, according to EN 60529 standard
- Motor Protection: Locked Rotor Protected
- Rotation: Clockwise
- Fixing system: by No 4 M4 screws
- Storage temperature: from -40°C to +70°C
- Rated temperature range: from -30°C to +70°C Lifetime L10 at 40°C: 70,000 h
- Electrical connection: 2 leads 22AWG UL 1007, 300 mm long.
- Weight: 0.55 kg
- Bearings: 2x Ball Bearings
- Safety Approvals: CE, ATEX
| Dimension | 120x120x38mm |
| Rated Voltage | 115-230V |
| Rated Power (50/60Hz) | 5.8Wa |
| Max Air Flow (m3/h) | 196 |
| Rated Speed (50/60Hz) (RPM) | 3000 (High) |
| Max Pressure (Pa) | 88 |
| Noise (50/60Hz) (dB(A)) | 45 |
| Bearing Type | Ball |
