D04D04HWSZ00 DC Axial Compact Fan 40x40x20mm 15m³/h 1.3W 12V Sleeve Bearing
SKU
D04D04HWSZ00
Buy 50 for
£4.03
each and save 5%
£4.24
| SKU | D04D04HWSZ00 |
|---|---|
| Lead Times | variable - contact us on 01782 349 430 |
| Manufacturer | FANDISEU |
| Current Type | DC |
| ATEX | No |
| Rated Voltage | 12V.d.c. |
| Dimensions | 40x40x20mm |
| Cable Length | 3.9"- 100mm |
| Max Air Flow (50Hz) | 15(m³/h) |
| Airflow Range (50Hz) | < 100m³/h |
| Bearing Type | Sleeve Bearing |
| Speed (RPM) | 1650 |
Description
Specially designed for control panels and enclosures, the DC compact axial fan range from Axair online offers:
- Compact sizes
- Ball & Sleeve Bearing options on many lines
- Dust and water protection
- A wide selection of airflows
Standard Specifications of the D04D04HWSZ00 DC Axial Compact Fan:
- Casing Material: Glass fibre reinforced plastic
- Impeller Material: Glass fibre reinforced plastic
- Motor protection: Impedance
- Rated temperature range: from -20°C to +70°C Lifetime L10 at 40°C: 70,000 h
- Electrical connection: 2 leads AWG26 UL1007 30mm long
- Weight: 0.17 kg
- Approvals: CE
