D04D05HWBZ00 24v DC Axial Compact Fan 40x40x20mm 15m³/h 2.2w Ball Bearing

Name: D04D05HWBZ00 24v DC Axial Compact Fan 40x40x20mm 15m³/h 2.2w Ball Bearing
SKU: D04D05HWBZ00
Price: 16.74 GBP
Availability: InStock

SKU

D04D05HWBZ00

Buy 50 for £15.90 each and save 5%

£16.74

Quantity

Lead time variable - contact us on 01782 349 430

SKU	D04D05HWBZ00
Lead Times	variable - contact us on 01782 349 430
Manufacturer	FANDISEU
Current Type	DC
ATEX	No
Dimensions	40x40x20mm
Cable Length	3.9"- 100mm
Max Air Flow (50Hz)	15(m³/h)
Airflow Range (50Hz)	< 100m³/h
Bearing Type	Ball Bearing
Speed (RPM)	1650

Description

Specially designed for control panels and enclosures, the DC Axial Compact Fan range from Axair online offers:

Compact sizes
Ball & Sleeve Bearing options on many lines
Dust and water protection
A wide selection of airflows

Standard Specifications of D04D05HWBZ00 DC Axial Compact Fan:

Casing Material: Black fibreglass reiforced plastic (PBT) UL 94V-0
Impeller Material: Black fibreglass reiforced plastic (PBT) UL 94V-0
Protection degree: IP20, according to EN 60529 standard
Fixing system: 4 holes Ø3.5mm
Electrical connection: 2 leads 26AWG UL 1007, 300 mm long
Motor protection: IC Storage temperature: from -40°C to +70°C
Rated temperature range: from -10°C to +70°C
Lifetime L10 at 40°C: 70,000 h
Weight: 28 g
Approvals: UL E223195

Dimension	40x40x20
Rated Voltage	24Vd.c
Rated Power (W)	2.2
Max Air Flow (m3/h)	15
Static Pressure (Pa)	70
Rated Speed (RPM)	7800
Noise (dB(A))	36.0
Bearing Type	Ball
