D17C05HWBA00 DC Axial Compact Fan 151x151x51mm 450m³/h 24W 24V Ball Bearing

Name: D17C05HWBA00 DC Axial Compact Fan 151x151x51mm 450m³/h 24W 24V Ball Bearing
SKU: D17C05HWBA00
Price: 162.45 GBP
Availability: InStock

SKU

D17C05HWBA00

Buy 40 for £154.33 each and save 5%

£162.45

Quantity

In Stock

View Downloads

SKU	D17C05HWBA00
Manufacturer	FANDISEU
Current Type	DC
Fan Type	DC Compact Axial Fan
ATEX	No
Rated Voltage	24V.d.c.
Frequency	50Hz
Dimensions	151x151x51mm
Connection Type	Cable
Cable Length	11"- 280mm
Max Air Flow (50Hz)	450(m³/h)
Airflow Range (50Hz)	250 to 500m³/h
Bearing Type	Ball Bearing
Speed (RPM)	3500
IP Rating	IP20

Description

Specially designed for control panels and enclosures, the DC axial compact fan range from Axair online offers:

Compact sizes
Ball & Sleeve Bearing options on many lines
Dust and water protection
A wide selection of airflows

Standard Specifications of D17C05HWBA00 DC Axial Compact Fan:

Casing material: aluminum alloy
Impeller material UL 94V-0 glass filled polyester (PBT)
Protection degree: IP20, according to EN 60529 standard
Fixing system: by No. 4 M4 screws
Motor protection: IC
Storage temperature: from -40°C to +70°C
Rated temperature range: from -10°C to +70°C
Lifetime L10 at 40°C: 70,000 h
Electrical connection: 2 leads 22AWG UL 1061, 300 mm long.
Approvals: UL E223195
Weight: 762g

Dimension	151x151x51
Rated Voltage	24 Vd.c.
Rated Power (W)	24
Max Air Flow (m3/h)	450
Static Pressure (Pa)	187
Rated Speed (RPM)	3500
Noise (dB(A))	58.8
Bearing Type	Ball
