HTM150 150W Metal Housing Enclosure Heater 110-240V AC/DC Terminal Block IP20

HTM150 150W Metal Housing Enclosure Heater 110-240V AC/DC Terminal Block IP20

SKU
HTM150
Buy 11 for £99.83 each and save 5%
£105.08
View Downloads
ManufacturerFANDISEU
Heating Power (w)150
Wiring TypeTerminal
Heater TypeMetallic with Terminal

Description

Axair heaters have a self regulating PTC element and are made from a black anodised aluminium.

Key Features of the HTM150:



  • Appliance Class: I
  • Frequency: 50/60 Hz
  • Max Current: 6.5 A
  • Operating Voltage: 99-264 V a.c.
  • Rated Voltage: 110-240 V a.c./d.c.
  • ENVIRONMENTAL AND THERMAL DATA
  • IP Protection Degree: IP20
  • Operating Temperature: -30÷50 °C
  • Storage Temperature: -40÷70 °C
  • GENERIC DATA
  • Casing Material: Black Anodised Aluminium
  • Electrical Connection: Terminal Block
  • Fixing System: DIN rail
  • Wires Section: 1-2.5 mm²
  • Wires Section: 20-16 AWG
  • PERFORMANCE: Heating Power 150 W
