E12B23LWBL00 EC Axial Compact Fan 120x120x38mm 132m³/h 2.5W 230V Ball Bearing
SKU
E12B23LWBL00
Buy 40 for
£21.93
each and save 5%
£23.08
| SKU | E12B23LWBL00 |
|---|---|
| Manufacturer | FANDISEU |
| Current Type | EC |
| Fan Type | EC Compact Axial Fan |
| ATEX | No |
| Rated Voltage | 230V.a.c |
| Frequency | 50-60Hz |
| Dimensions | 120x120x38mm |
| Connection Type | Cable |
| Cable Length | 11.8" - 300mm |
| Max Air Flow (50Hz) | 132(m³/h) |
| Airflow Range (50Hz) | 100 to 250m³/h |
| Bearing Type | Ball Bearing |
| Speed (RPM) | 2000 |
| IP Rating | IP20 |
Description
Specially designed for control panels and enclosures, the EC Axial Compact Fan range from Axair online offers:
- Compact sizes
- Ball & Sleeve Bearing options on many lines
- Dust and water protection
- A wide selection of airflows
Standard Specifications of E12B23LWBL00 EC Axial Compact Fan:
- Casing Material: Thermoplastic in black color, UL 94 V-0
- Impeller Material: Thermoplastic in black color, UL 94 V-0
- Protection degree: IP20, according to EN 60529 standard
- Fixing system: by No 4 M4 screws
- Motor protection: Impedance
- Storage temperature: from -40°C to +75°C
- Rated temperature range: from -10°C to +70°C Lifetime L10 at 25°C: 50,000 h
- Electrical connection: 2 leads 24 AWG UL1430
- Weight: 0.270 kg
- Approvals: CE
| Dimension | 120x120x38 |
| Rated Voltage | 230Va.c |
| Rated Power (50/60Hz) | 2.5 |
| Max Air Flow (m3/h) | 132/138 |
| Static Pressure (50/60Hz) | 37/37 |
| Rated Speed (50/60Hz) (RPM) | 2000/2100 |
| Noise (50/60Hz) (dB(A)) | 34.0/35.7 |
| Bearing Type | Ball |
